Tray dispenser trolley
Product number: 525-1400TB / 525-1400TBGN / 525-1400TBSP
Choose variation
Product specifications
Function
In common
Stackable tray trolley.
Saves space – Simplifies handling.
- Reduces the area required by approx. 65%. Uses only 210 mm per trolley when stacked together.
- Easy to push several at a time – saves time and effort.
- Orderliness and efficient storage.
- Frames identical, easy to change loading plane between tray sizes and tray and basket.
Properties
In common
As the loading planes can be raised and the frame with the wheels can be inserted in each other, it is possible to stack the trolleys. Tray dispensers can be stacked together.
The trolley is made from stainless steel, SIS 2320. It has a solid stainless handle and high quality Ø125 mm ball bearing castors, two with brakes. Compact packaging reduces the freight cost.
Design Patent
Cleaning
In common
With all-purpose cleaners, foam cleaning or in a trolley washer type WD 18 CW.
Dimensions
Product nr: 525-1400TB
For tray 33x43 cm
Length
730 mm
Width
400 mm
Height
1000 mm
Capacity
Approx. 80 trays
Inserted in each other additional trolleys build
210 mm lengthwise
Product nr: 525-1400TBGN
For tray GN 1/132,5x53 cm
Length
730 mm
Width
400 mm
Height
1000 mm
Capacity
Approx. 80 trays
Inserted in each other additional trolleys build
210 mm lengthwise
Product nr: 525-1400TBSP
For tray other specification
Capacity
Approx. 80 trays
